Manufacturer code: KrRT-7237С
Rotary Shaft Seal AS 28х47x7 NBR-440 blue DIN 3760
28х47х7, 28*47*7, 28x47x7, 28-47-7, oil-seal
SIZES
Size, mm:
28х47х7
d (shaft):
28
D (bore):
47
h (height):
7
RUBBER
Material:
Nitrile-butadiene rubber (NBR)
Color:
Blue
Rubber type acc. to standard:
2 (NBR, -30° ... +100°C)
CHARACTERISTICS
Dust protection:
with dustlip
Shaft rotation:
reverse (without hydrodynamic helixes)
Construction:
metal case fully rubberred
Design code:
BASLX7
Working edge type
mechanically trimmed
CORRESPONDENCE
Seal correspondence to seal by GOST 8752-79/DIN 3760:
2.1-28х47-2 (2.2-28х47-2)
CTB 75.13.00-01 Rubber-metal shaft seal of seeder Todak, Multicorn [187x220x12]
Rotary Shaft Seal AS 28х47x7 NBR DIN 3760
Rotary Shaft Seal AS 28х47x7 FKM DIN 3760
